Class-Leading Power to Weight

More than a decade on from starting the four stroke revolution with its award winning DF70 and DF60 outboards, Suzuki has reinvented the category again its latest series of mechanical high performance outboards.

Suzuki’s new generation four-strokes showcase an array of advancements and achievements – such as digital sequential electronic fuel injection, a powerful 2.59:1 final drive ratio, zero-maintenance self-adjusting time chain and don’t forget the Suzuki Lean Burn Control System. The Suzuki Troll Mode System is also available as an option.

Discover Suzuki's 3+3 year Warranty for recreational used outboards, plus other terms and conditions for commercial and government registered outboards under  Suzuki's Warranty Policy.

2-Stage Gear Reduction

This system which incorporates the Offset Driveshaft features a first stage reduction between the crankshaft and drive shaft and a second stage reduction inside the gear case. This design makes a larger gear ratio possible, allowing it to turn a large diameter propeller for high propulsive efficiency while providing high torque.

ADVANTAGES

■ High propulsive efficiency with large diameter propeller.
■ Powerful navigation, maintaining propeller rotation even with a larger load.
■ Tremendous power to turn large diameter propellers, offering quick acceleration.

Offset Driveshaft

The engine powerhead is positioned closer to the front, moving the outboard's centre of gravity forward.

ADVANTAGES

■ Less vibration.
■ More compact engine design.
■ Stable steering performance.

3 + 3 years Recreational Warranty

All recreational/privately registered Suzuki Outboards come standard with 3-years / unlimited hours manufacturer’s warranty. Recreational outboards are also eligible for a bonus 3-year Warranty providing that an authorised Suzuki Marine Dealership completes servicing as per the owners manual schedule. The Suzuki dealer must use only genuine parts and oils during both manufacturer’s and bonus warranty periods.

Features

Specifications

Recommended Transom Height L: 508mm, X: 635mm
Weight Tiller: L: 162kg
Valve Train DOHC 16-Valve
Displacement 1,502cm³
Maximum Output 66.2kW
Control System Mechanical
Recommended Fuel RON91 / AKI87
Alternator 12V 27A
Gear Ratio 2.59 : 1 (Two-stage gear reduction)
Exhaust Through Prop Hub Exhaust
Starting system Electric
Engine Type In-line 4 cylinder, 4-stroke
Fuel Delivery System Electronic Fuel Injection
Bore X Stroke 75 x 85mm
Full Throttle Operating Range 5,700 - 6,300rpm
Oil Pan Capacity 4.3L
Fuel Tank Capacity Separate 25L (optional)
Trim Method Power Trim and Tilt
Gear Shift F-N-R
Propeller Selection (Pitch) 13" - 25" (R/R)
